Features | Details | Unit |
Screen Size (Diagonal) | 1.77” | |
Panel type | TN | |
Display Mode | Transmissive /Normally White | |
Resolution | 128RGB x 160 | |
View Direction(human Eye) | 6 O’clock | Best Image |
Module Outline | 34.7 (H) x 46.75 (V) x 2.25 (T) | mm |
Active Area | 28.032(H) x35.04(V) | mm |
Dot Size | 0.219(H) x 0.219 (V) | mm |
Pixel Arrangement | -Strip | |
Polarizer Surface Treatment | Anti-Glare | |
Interface | 8bit MCUinterface | |
Driver IC | ILI9163V | - |
With or Without Touch Panel | Without | |
Operating Temperature | -20~70 | °C |
Storage Temperature | -30~80 | °C |
Weight | TBD | g |
Recommend connector | - |
