Features | Details | Unit |
Screen Size (Diagonal) | 10.1” | |
Panel type | IPS | |
Display Mode | Transmissive /Normally Black | |
Resolution | 1280RGB x 800 | |
View Direction(human Eye) | FULL VIEW O’clock | Best Image |
Module Outline | 229.46 (H) x 149.1 (V) x 2.5(T) | mm |
Active Area | 216.95(H) x 135.6(V) | mm |
Dot Size | 0.1695 (H) x 0.1695 (V) | mm |
Pixel Arrangement | -Strip | |
Polarizer Surface Treatment | Anti-Glare | |
Interface | 6 or 8-bit LVDS interface | |
Display color | 262K or 16.7M | |
Driver IC | - | - |
With or Without Touch Panel | Without | |
Operating Temperature | -20~70 | °C |
Storage Temperature | -30~80 | °C |
Weight | TBD | g |
Recommend connector | - |
